  • starmobile v3 blackout jtag done

    problem : blackout unit by sir blaze25(orig thread= http://www.gsmworldfive.com/forum/sh...=starmobile+v3 )

    solution : jtag by ATF

    tools :
    * atf box jtag activated
    * usb cable
    * uart old cable (pwede yung sa mga nokia)

    procedure :
    * download first firmware here
    http://atfsupport.com/?dir=file-supp...%20AFP%20Files
    * dismantle phone,remove all connected parts like lcd and ts (para madetect ng maayos ang qualcom ic)
    * load firmware na dinownload nyo para makita pinout ng phone
    * dahil uart cable gamit ko ,number coding ginamit ko sa pag solder at pagsunod sa pinout..(wag nyo sundin ang color coding for sure di madedetect ang phone)
    * after soldering pinout connect uart cable tapos saksak nyo usb cable yun magiging supply nya ,no need battery
    * kulitin nyo lang minsan may error
    * hintayin matapos flashing

    flashing :





    Last edited by marvin62; 11-16-2015, 08:17 PM.

    Read and always follow forum rules

    gsmworldfive 2016 rules




    mga kasangga ko
    "sana magtulungan tayong lahat walang bagsak presyo at walang siraan sa kapwa tech.

    ym:marvin6214
    phone no:09499426474

  • #2
    Paano po gamitin ang number coding sa old UART cable sir marvz? Baguhan here.
    READ RULES: FORUM RULES
    NEW MEMBERS: FORUM HOW TO
    READ FORUM FAQ: FAQ LINK

    <marquee behavior="scroll" direction="left" scrollamount="5">Forced kindness deserves no thanks, willingness to serve does not wait until it is ask for.</marquee><marquee behavior="scroll" direction="up" scrollamount="5">
    ΑΦΩ</marquee>

    <a href="http://photobucket.com/images/moving%20animations" target="_blank"><img src="http://i641.photobucket.com/albums/uu136/lllisalllindsay/Animated/gifs_animations_17.gif" border="0" alt="moving animations photo: animations gifs_animations_17.gif"/></a>
    Apple Firmwares
    Nokia Firmwares

    Comment


    • #3
      tnx bos sa pagshare,,,,,,,,,,,,,,,,,,
      ''DI bali nang MATAKAW,,,,,,wag lang MAGNANAKAW..(''.)..''

      Comment


      • #4
        salamat sa pagbahagi
